pcbnew.PLOT_CONTROLLER Class Reference

Inheritance diagram for pcbnew.PLOT_CONTROLLER:

Public Member Functions
def	__init__ (self, aBoard)
def	GetPlotOptions (self)
def	SetLayer (self, aLayer)
def	GetLayer (self)
def	IsPlotOpen (self)
def	ClosePlot (self)
def	OpenPlotfile (self, *args)
def	PlotLayer (self)
def	PlotLayers (self, aLayerSequence)
def	GetPlotFileName (self)
def	GetPlotDirName (self)
def	SetColorMode (self, aColorMode)
def	GetColorMode (self)
def	GetPlotter (self)

Properties
property	thisown = property(lambda x: x.this.own(), lambda x, v: x.this.own(v), doc="The membership flag")

Detailed Description

Proxy of C++ PLOT_CONTROLLER class.

Definition at line 7940 of file pcbnew.py.

Constructor & Destructor Documentation

__init__()

def pcbnew.PLOT_CONTROLLER.__init__	(		self,
			aBoard
	)

__init__(PLOT_CONTROLLER self, BOARD aBoard) -> PLOT_CONTROLLER

Definition at line 7946 of file pcbnew.py.

Member Function Documentation

ClosePlot()

def pcbnew.PLOT_CONTROLLER.ClosePlot

(

self

)

ClosePlot(PLOT_CONTROLLER self)

Definition at line 7967 of file pcbnew.py.

GetColorMode()

def pcbnew.PLOT_CONTROLLER.GetColorMode

(

self

)

GetColorMode(PLOT_CONTROLLER self) -> bool

Definition at line 7995 of file pcbnew.py.

GetLayer()

def pcbnew.PLOT_CONTROLLER.GetLayer

(

self

)

GetLayer(PLOT_CONTROLLER self) -> int

Definition at line 7959 of file pcbnew.py.

Here is the caller graph for this function:

GetPlotDirName()

def pcbnew.PLOT_CONTROLLER.GetPlotDirName

(

self

)

GetPlotDirName(PLOT_CONTROLLER self) -> wxString

Definition at line 7987 of file pcbnew.py.

GetPlotFileName()

def pcbnew.PLOT_CONTROLLER.GetPlotFileName

(

self

)

GetPlotFileName(PLOT_CONTROLLER self) -> wxString

Definition at line 7983 of file pcbnew.py.

GetPlotOptions()

def pcbnew.PLOT_CONTROLLER.GetPlotOptions

(

self

)

GetPlotOptions(PLOT_CONTROLLER self) -> PCB_PLOT_PARAMS

Definition at line 7951 of file pcbnew.py.

GetPlotter()

def pcbnew.PLOT_CONTROLLER.GetPlotter

(

self

)

GetPlotter(PLOT_CONTROLLER self) -> PLOTTER

Definition at line 7999 of file pcbnew.py.

IsPlotOpen()

def pcbnew.PLOT_CONTROLLER.IsPlotOpen

(

self

)

IsPlotOpen(PLOT_CONTROLLER self) -> bool

Definition at line 7963 of file pcbnew.py.

OpenPlotfile()

def pcbnew.PLOT_CONTROLLER.OpenPlotfile	(		self,
		*	args
	)

OpenPlotfile(PLOT_CONTROLLER self, wxString aSuffix, PLOT_FORMAT aFormat, wxString aSheetName=wxEmptyString, wxString aSheetPath=wxEmptyString) -> bool

Definition at line 7971 of file pcbnew.py.

PlotLayer()

def pcbnew.PLOT_CONTROLLER.PlotLayer

(

self

)

PlotLayer(PLOT_CONTROLLER self) -> bool

Definition at line 7975 of file pcbnew.py.

PlotLayers()

def pcbnew.PLOT_CONTROLLER.PlotLayers	(		self,
			aLayerSequence
	)

PlotLayers(PLOT_CONTROLLER self, LSEQ aLayerSequence) -> bool

Definition at line 7979 of file pcbnew.py.

SetColorMode()

def pcbnew.PLOT_CONTROLLER.SetColorMode	(		self,
			aColorMode
	)

SetColorMode(PLOT_CONTROLLER self, bool aColorMode)

Definition at line 7991 of file pcbnew.py.

SetLayer()

def pcbnew.PLOT_CONTROLLER.SetLayer	(		self,
			aLayer
	)

SetLayer(PLOT_CONTROLLER self, int aLayer)

Definition at line 7955 of file pcbnew.py.

Property Documentation

thisown

property pcbnew.PLOT_CONTROLLER.thisown = property(lambda x: x.this.own(), lambda x, v: x.this.own(v), doc="The membership flag")

static

Definition at line 7943 of file pcbnew.py.

---

The documentation for this class was generated from the following file:

• pcbnew.py
