Inheritance diagram for pcbnew.BOARD_DESIGN_SETTINGS:

Public Member Functions
def	__eq__ (self, aOther)

def	__ne__ (self, aOther)

def	__init__ (self, *args)

def	LoadFromFile (self, *args)

def	GetStackupDescriptor (self, *args)

def	GetTeadropParamsList (self)

def	GetSeverity (self, aDRCErrorCode)

def	Ignore (self, aDRCErrorCode)

def	GetDefaultZoneSettings (self)

def	SetDefaultZoneSettings (self, aSettings)

def	GetCurrentNetClassName (self)

def	UseNetClassTrack (self)

def	UseNetClassVia (self)

def	UseNetClassDiffPair (self)

def	GetBiggestClearanceValue (self)

def	GetSmallestClearanceValue (self)

def	GetTrackWidthIndex (self)

def	SetTrackWidthIndex (self, aIndex)

def	GetCurrentTrackWidth (self)

def	SetCustomTrackWidth (self, aWidth)

def	GetCustomTrackWidth (self)

def	GetViaSizeIndex (self)

def	SetViaSizeIndex (self, aIndex)

def	GetCurrentViaSize (self)

def	SetCustomViaSize (self, aSize)

def	GetCustomViaSize (self)

def	GetCurrentViaDrill (self)

def	SetCustomViaDrill (self, aDrill)

def	GetCustomViaDrill (self)

def	UseCustomTrackViaSize (self, *args)

def	GetDiffPairIndex (self)

def	SetDiffPairIndex (self, aIndex)

def	SetCustomDiffPairWidth (self, aWidth)

def	GetCustomDiffPairWidth (self)

def	SetCustomDiffPairGap (self, aGap)

def	GetCustomDiffPairGap (self)

def	SetCustomDiffPairViaGap (self, aGap)

def	GetCustomDiffPairViaGap (self)

def	UseCustomDiffPairDimensions (self, *args)

def	GetCurrentDiffPairWidth (self)

def	GetCurrentDiffPairGap (self)

def	GetCurrentDiffPairViaGap (self)

def	GetEnabledLayers (self)

def	SetEnabledLayers (self, aMask)

def	IsLayerEnabled (self, aLayerId)

def	GetCopperLayerCount (self)

def	SetCopperLayerCount (self, aNewLayerCount)

def	GetUserDefinedLayerCount (self)

def	SetUserDefinedLayerCount (self, aNewLayerCount)

def	GetBoardThickness (self)

def	SetBoardThickness (self, aThickness)

def	GetDRCEpsilon (self)

def	GetHolePlatingThickness (self)

def	GetLineThickness (self, aLayer)

def	GetTextSize (self, aLayer)

def	GetTextThickness (self, aLayer)

def	GetTextItalic (self, aLayer)

def	GetTextUpright (self, aLayer)

def	GetLayerClass (self, aLayer)

def	SetAuxOrigin (self, aOrigin)

def	GetAuxOrigin (self)

def	SetGridOrigin (self, aOrigin)

def	GetGridOrigin (self)

def	SetDefaultMasterPad (self)

def	CloneFrom (self, aOther)

Properties
property	thisown = property(lambda x: x.this.own(), lambda x, v: x.this.own(v), doc="The membership flag")

property	m_TrackWidthList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TrackWidthList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TrackWidthList_set, doc=)

property	m_ViasDimensionsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasDimensionsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasDimensionsList_set, doc=)

property	m_DiffPairDimensionsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairDimensionsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairDimensionsList_set, doc=)

property	m_TeardropParamsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TeardropParamsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TeardropParamsList_set, doc=)

property	m_SingleTrackMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SingleTrackMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SingleTrackMeanderSettings_set, doc=)

property	m_DiffPairMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairMeanderSettings_set, doc=)

property	m_SkewMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SkewMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SkewMeanderSettings_set, doc=)

property	m_CurrentViaType = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CurrentViaType_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CurrentViaType_set, doc=)

property	m_UseConnectedTrackWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UseConnectedTrackWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UseConnectedTrackWidth_set, doc=)

property	m_TempOverrideTrackWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TempOverrideTrackWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TempOverrideTrackWidth_set, doc=)

property	m_MinClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinClearance_set, doc=)

property	m_MinGrooveWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinGrooveWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinGrooveWidth_set, doc=)

property	m_MinConn = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinConn_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinConn_set, doc=)

property	m_TrackMinWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TrackMinWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TrackMinWidth_set, doc=)

property	m_ViasMinAnnularWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinAnnularWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinAnnularWidth_set, doc=)

property	m_ViasMinSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinSize_set, doc=)

property	m_MinThroughDrill = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinThroughDrill_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinThroughDrill_set, doc=)

property	m_MicroViasMinSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinSize_set, doc=)

property	m_MicroViasMinDrill = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinDrill_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinDrill_set, doc=)

property	m_CopperEdgeClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CopperEdgeClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CopperEdgeClearance_set, doc=)

property	m_HoleClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HoleClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HoleClearance_set, doc=)

property	m_HoleToHoleMin = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HoleToHoleMin_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HoleToHoleMin_set, doc=)

property	m_SilkClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SilkClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SilkClearance_set, doc=)

property	m_MinResolvedSpokes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinResolvedSpokes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinResolvedSpokes_set, doc=)

property	m_MinSilkTextHeight = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextHeight_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextHeight_set, doc=)

property	m_MinSilkTextThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextThickness_set, doc=)

property	m_DRCSeverities = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DRCSeverities_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DRCSeverities_set, doc=)

property	m_DrcExclusions = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusions_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusions_set, doc=)

property	m_DrcExclusionComments = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusionComments_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusionComments_set, doc=)

property	m_ZoneKeepExternalFillets = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneKeepExternalFillets_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneKeepExternalFillets_set, doc=)

property	m_MaxError = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MaxError_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MaxError_set, doc=)

property	m_SolderMaskExpansion = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskExpansion_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskExpansion_set, doc=)

property	m_SolderMaskMinWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskMinWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskMinWidth_set, doc=)

property	m_SolderMaskToCopperClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskToCopperClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskToCopperClearance_set, doc=)

property	m_SolderPasteMargin = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMargin_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMargin_set, doc=)

property	m_SolderPasteMarginRatio = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMarginRatio_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMarginRatio_set, doc=)

property	m_AllowSoldermaskBridgesInFPs = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_AllowSoldermaskBridgesInFPs_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_AllowSoldermaskBridgesInFPs_set, doc=)

property	m_TentViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasFront_set, doc=)

property	m_TentViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasBack_set, doc=)

property	m_CoverViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasFront_set, doc=)

property	m_CoverViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasBack_set, doc=)

property	m_PlugViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasFront_set, doc=)

property	m_PlugViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasBack_set, doc=)

property	m_CapVias = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CapVias_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CapVias_set, doc=)

property	m_FillVias = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_FillVias_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_FillVias_set, doc=)

property	m_NetSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_NetSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_NetSettings_set, doc=)

property	m_DefaultFPTextItems = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DefaultFPTextItems_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DefaultFPTextItems_set, doc=)

property	m_UserLayerNames = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UserLayerNames_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UserLayerNames_set, doc=)

property	m_LineThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_LineThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_LineThickness_set, doc=)

property	m_TextSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextSize_set, doc=)

property	m_TextThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextThickness_set, doc=)

property	m_TextItalic = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextItalic_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextItalic_set, doc=)

property	m_TextUpright = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextUpright_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextUpright_set, doc=)

property	m_DimensionUnitsMode = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsMode_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsMode_set, doc=)

property	m_DimensionPrecision = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionPrecision_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionPrecision_set, doc=)

property	m_DimensionUnitsFormat = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsFormat_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsFormat_set, doc=)

property	m_DimensionSuppressZeroes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionSuppressZeroes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionSuppressZeroes_set, doc=)

property	m_DimensionTextPosition = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionTextPosition_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionTextPosition_set, doc=)

property	m_DimensionKeepTextAligned = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionKeepTextAligned_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionKeepTextAligned_set, doc=)

property	m_DimensionArrowLength = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionArrowLength_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionArrowLength_set, doc=)

property	m_DimensionExtensionOffset = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionExtensionOffset_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionExtensionOffset_set, doc=)

property	m_StyleFPFields = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPFields_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPFields_set, doc=)

property	m_StyleFPText = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPText_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPText_set, doc=)

property	m_StyleFPShapes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPShapes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPShapes_set, doc=)

property	m_HasStackup = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HasStackup_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HasStackup_set, doc=)

property	m_UseHeightForLengthCalcs = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UseHeightForLengthCalcs_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UseHeightForLengthCalcs_set, doc=)

Detailed Description

Proxy of C++ BOARD_DESIGN_SETTINGS class.

Definition at line 11113 of file pcbnew.py.

Constructor & Destructor Documentation

◆ init()

def pcbnew.BOARD_DESIGN_SETTINGS.__init__	(		self,
		*	args
	)

    __init__(BOARD_DESIGN_SETTINGS self, JSON_SETTINGS * aParent, string aPath) -> BOARD_DESIGN_SETTINGS
    __init__(BOARD_DESIGN_SETTINGS self, BOARD_DESIGN_SETTINGS aOther) -> BOARD_DESIGN_SETTINGS

Definition at line 11128 of file pcbnew.py.

Here is the caller graph for this function:

Member Function Documentation

◆ eq()

def pcbnew.BOARD_DESIGN_SETTINGS.__eq__	(	self,
		aOther
	)

__eq__(BOARD_DESIGN_SETTINGS self, BOARD_DESIGN_SETTINGS aOther) -> bool

Definition at line 11120 of file pcbnew.py.

◆ ne()

def pcbnew.BOARD_DESIGN_SETTINGS.__ne__	(	self,
		aOther
	)

__ne__(BOARD_DESIGN_SETTINGS self, BOARD_DESIGN_SETTINGS aOther) -> bool

Definition at line 11124 of file pcbnew.py.

◆ CloneFrom()

def pcbnew.BOARD_DESIGN_SETTINGS.CloneFrom	(	self,
		aOther
	)

CloneFrom(BOARD_DESIGN_SETTINGS self, BOARD_DESIGN_SETTINGS aOther)

Definition at line 11454 of file pcbnew.py.

◆ GetAuxOrigin()

def pcbnew.BOARD_DESIGN_SETTINGS.GetAuxOrigin ( self )

GetAuxOrigin(BOARD_DESIGN_SETTINGS self) -> VECTOR2I

Definition at line 11372 of file pcbnew.py.

◆ GetBiggestClearanceValue()

def pcbnew.BOARD_DESIGN_SETTINGS.GetBiggestClearanceValue ( self )

GetBiggestClearanceValue(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11182 of file pcbnew.py.

◆ GetBoardThickness()

def pcbnew.BOARD_DESIGN_SETTINGS.GetBoardThickness ( self )

GetBoardThickness(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11328 of file pcbnew.py.

◆ GetCopperLayerCount()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCopperLayerCount ( self )

GetCopperLayerCount(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11312 of file pcbnew.py.

◆ GetCurrentDiffPairGap()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentDiffPairGap ( self )

GetCurrentDiffPairGap(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11292 of file pcbnew.py.

◆ GetCurrentDiffPairViaGap()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentDiffPairViaGap ( self )

GetCurrentDiffPairViaGap(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11296 of file pcbnew.py.

◆ GetCurrentDiffPairWidth()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentDiffPairWidth ( self )

GetCurrentDiffPairWidth(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11288 of file pcbnew.py.

◆ GetCurrentNetClassName()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentNetClassName ( self )

GetCurrentNetClassName(BOARD_DESIGN_SETTINGS self) -> wxString

Definition at line 11166 of file pcbnew.py.

◆ GetCurrentTrackWidth()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentTrackWidth ( self )

GetCurrentTrackWidth(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11198 of file pcbnew.py.

◆ GetCurrentViaDrill()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentViaDrill ( self )

GetCurrentViaDrill(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11230 of file pcbnew.py.

◆ GetCurrentViaSize()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentViaSize ( self )

GetCurrentViaSize(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11218 of file pcbnew.py.

◆ GetCustomDiffPairGap()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCustomDiffPairGap ( self )

GetCustomDiffPairGap(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11269 of file pcbnew.py.

◆ GetCustomDiffPairViaGap()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCustomDiffPairViaGap ( self )

GetCustomDiffPairViaGap(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11277 of file pcbnew.py.

◆ GetCustomDiffPairWidth()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCustomDiffPairWidth ( self )

GetCustomDiffPairWidth(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11261 of file pcbnew.py.

◆ GetCustomTrackWidth()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCustomTrackWidth ( self )

GetCustomTrackWidth(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11206 of file pcbnew.py.

◆ GetCustomViaDrill()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCustomViaDrill ( self )

GetCustomViaDrill(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11238 of file pcbnew.py.

◆ GetCustomViaSize()

def pcbnew.BOARD_DESIGN_SETTINGS.GetCustomViaSize ( self )

GetCustomViaSize(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11226 of file pcbnew.py.

◆ GetDefaultZoneSettings()

def pcbnew.BOARD_DESIGN_SETTINGS.GetDefaultZoneSettings ( self )

GetDefaultZoneSettings(BOARD_DESIGN_SETTINGS self) -> ZONE_SETTINGS

Definition at line 11158 of file pcbnew.py.

◆ GetDiffPairIndex()

def pcbnew.BOARD_DESIGN_SETTINGS.GetDiffPairIndex ( self )

GetDiffPairIndex(BOARD_DESIGN_SETTINGS self) -> unsigned int

Definition at line 11249 of file pcbnew.py.

◆ GetDRCEpsilon()

def pcbnew.BOARD_DESIGN_SETTINGS.GetDRCEpsilon ( self )

GetDRCEpsilon(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11336 of file pcbnew.py.

◆ GetEnabledLayers()

def pcbnew.BOARD_DESIGN_SETTINGS.GetEnabledLayers ( self )

GetEnabledLayers(BOARD_DESIGN_SETTINGS self) -> LSET

Definition at line 11300 of file pcbnew.py.

◆ GetGridOrigin()

def pcbnew.BOARD_DESIGN_SETTINGS.GetGridOrigin ( self )

GetGridOrigin(BOARD_DESIGN_SETTINGS self) -> VECTOR2I

Definition at line 11380 of file pcbnew.py.

◆ GetHolePlatingThickness()

def pcbnew.BOARD_DESIGN_SETTINGS.GetHolePlatingThickness ( self )

GetHolePlatingThickness(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11340 of file pcbnew.py.

◆ GetLayerClass()

def pcbnew.BOARD_DESIGN_SETTINGS.GetLayerClass	(	self,
		aLayer
	)

GetLayerClass(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> int

Definition at line 11364 of file pcbnew.py.

◆ GetLineThickness()

def pcbnew.BOARD_DESIGN_SETTINGS.GetLineThickness	(	self,
		aLayer
	)

GetLineThickness(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> int

Definition at line 11344 of file pcbnew.py.

Here is the caller graph for this function:

◆ GetSeverity()

def pcbnew.BOARD_DESIGN_SETTINGS.GetSeverity	(	self,
		aDRCErrorCode
	)

GetSeverity(BOARD_DESIGN_SETTINGS self, int aDRCErrorCode) -> SEVERITY

Definition at line 11150 of file pcbnew.py.

◆ GetSmallestClearanceValue()

def pcbnew.BOARD_DESIGN_SETTINGS.GetSmallestClearanceValue ( self )

GetSmallestClearanceValue(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11186 of file pcbnew.py.

◆ GetStackupDescriptor()

def pcbnew.BOARD_DESIGN_SETTINGS.GetStackupDescriptor	(		self,
		*	args
	)

    GetStackupDescriptor(BOARD_DESIGN_SETTINGS self) -> BOARD_STACKUP
    GetStackupDescriptor(BOARD_DESIGN_SETTINGS self) -> BOARD_STACKUP const &

Definition at line 11139 of file pcbnew.py.

Here is the caller graph for this function:

◆ GetTeadropParamsList()

def pcbnew.BOARD_DESIGN_SETTINGS.GetTeadropParamsList ( self )

GetTeadropParamsList(BOARD_DESIGN_SETTINGS self) -> TEARDROP_PARAMETERS_LIST *

Definition at line 11146 of file pcbnew.py.

◆ GetTextItalic()

def pcbnew.BOARD_DESIGN_SETTINGS.GetTextItalic	(	self,
		aLayer
	)

GetTextItalic(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> bool

Definition at line 11356 of file pcbnew.py.

◆ GetTextSize()

def pcbnew.BOARD_DESIGN_SETTINGS.GetTextSize	(	self,
		aLayer
	)

GetTextSize(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> VECTOR2I

Definition at line 11348 of file pcbnew.py.

◆ GetTextThickness()

def pcbnew.BOARD_DESIGN_SETTINGS.GetTextThickness	(	self,
		aLayer
	)

GetTextThickness(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> int

Definition at line 11352 of file pcbnew.py.

◆ GetTextUpright()

def pcbnew.BOARD_DESIGN_SETTINGS.GetTextUpright	(	self,
		aLayer
	)

GetTextUpright(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> bool

Definition at line 11360 of file pcbnew.py.

◆ GetTrackWidthIndex()

def pcbnew.BOARD_DESIGN_SETTINGS.GetTrackWidthIndex ( self )

GetTrackWidthIndex(BOARD_DESIGN_SETTINGS self) -> unsigned int

Definition at line 11190 of file pcbnew.py.

◆ GetUserDefinedLayerCount()

def pcbnew.BOARD_DESIGN_SETTINGS.GetUserDefinedLayerCount ( self )

GetUserDefinedLayerCount(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11320 of file pcbnew.py.

◆ GetViaSizeIndex()

def pcbnew.BOARD_DESIGN_SETTINGS.GetViaSizeIndex ( self )

GetViaSizeIndex(BOARD_DESIGN_SETTINGS self) -> unsigned int

Definition at line 11210 of file pcbnew.py.

◆ Ignore()

def pcbnew.BOARD_DESIGN_SETTINGS.Ignore	(	self,
		aDRCErrorCode
	)

Ignore(BOARD_DESIGN_SETTINGS self, int aDRCErrorCode) -> bool

Definition at line 11154 of file pcbnew.py.

◆ IsLayerEnabled()

def pcbnew.BOARD_DESIGN_SETTINGS.IsLayerEnabled	(	self,
		aLayerId
	)

IsLayerEnabled(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayerId) -> bool

Definition at line 11308 of file pcbnew.py.

◆ LoadFromFile()

def pcbnew.BOARD_DESIGN_SETTINGS.LoadFromFile	(		self,
		*	args
	)

LoadFromFile(BOARD_DESIGN_SETTINGS self, wxString aDirectory="") -> bool

Definition at line 11135 of file pcbnew.py.

◆ SetAuxOrigin()

def pcbnew.BOARD_DESIGN_SETTINGS.SetAuxOrigin	(	self,
		aOrigin
	)

SetAuxOrigin(BOARD_DESIGN_SETTINGS self, VECTOR2I aOrigin)

Definition at line 11368 of file pcbnew.py.

◆ SetBoardThickness()

def pcbnew.BOARD_DESIGN_SETTINGS.SetBoardThickness	(	self,
		aThickness
	)

SetBoardThickness(BOARD_DESIGN_SETTINGS self, int aThickness)

Definition at line 11332 of file pcbnew.py.

◆ SetCopperLayerCount()

def pcbnew.BOARD_DESIGN_SETTINGS.SetCopperLayerCount	(	self,
		aNewLayerCount
	)

SetCopperLayerCount(BOARD_DESIGN_SETTINGS self, int aNewLayerCount)

Definition at line 11316 of file pcbnew.py.

◆ SetCustomDiffPairGap()

def pcbnew.BOARD_DESIGN_SETTINGS.SetCustomDiffPairGap	(	self,
		aGap
	)

SetCustomDiffPairGap(BOARD_DESIGN_SETTINGS self, int aGap)

Definition at line 11265 of file pcbnew.py.

◆ SetCustomDiffPairViaGap()

def pcbnew.BOARD_DESIGN_SETTINGS.SetCustomDiffPairViaGap	(	self,
		aGap
	)

SetCustomDiffPairViaGap(BOARD_DESIGN_SETTINGS self, int aGap)

Definition at line 11273 of file pcbnew.py.

◆ SetCustomDiffPairWidth()

def pcbnew.BOARD_DESIGN_SETTINGS.SetCustomDiffPairWidth	(	self,
		aWidth
	)

SetCustomDiffPairWidth(BOARD_DESIGN_SETTINGS self, int aWidth)

Definition at line 11257 of file pcbnew.py.

◆ SetCustomTrackWidth()

def pcbnew.BOARD_DESIGN_SETTINGS.SetCustomTrackWidth	(	self,
		aWidth
	)

SetCustomTrackWidth(BOARD_DESIGN_SETTINGS self, int aWidth)

Definition at line 11202 of file pcbnew.py.

◆ SetCustomViaDrill()

def pcbnew.BOARD_DESIGN_SETTINGS.SetCustomViaDrill	(	self,
		aDrill
	)

SetCustomViaDrill(BOARD_DESIGN_SETTINGS self, int aDrill)

Definition at line 11234 of file pcbnew.py.

◆ SetCustomViaSize()

def pcbnew.BOARD_DESIGN_SETTINGS.SetCustomViaSize	(	self,
		aSize
	)

SetCustomViaSize(BOARD_DESIGN_SETTINGS self, int aSize)

Definition at line 11222 of file pcbnew.py.

◆ SetDefaultMasterPad()

def pcbnew.BOARD_DESIGN_SETTINGS.SetDefaultMasterPad ( self )

SetDefaultMasterPad(BOARD_DESIGN_SETTINGS self)

Definition at line 11384 of file pcbnew.py.

◆ SetDefaultZoneSettings()

def pcbnew.BOARD_DESIGN_SETTINGS.SetDefaultZoneSettings	(	self,
		aSettings
	)

SetDefaultZoneSettings(BOARD_DESIGN_SETTINGS self, ZONE_SETTINGS aSettings)

Definition at line 11162 of file pcbnew.py.

◆ SetDiffPairIndex()

def pcbnew.BOARD_DESIGN_SETTINGS.SetDiffPairIndex	(	self,
		aIndex
	)

SetDiffPairIndex(BOARD_DESIGN_SETTINGS self, unsigned int aIndex)

Definition at line 11253 of file pcbnew.py.

◆ SetEnabledLayers()

def pcbnew.BOARD_DESIGN_SETTINGS.SetEnabledLayers	(	self,
		aMask
	)

SetEnabledLayers(BOARD_DESIGN_SETTINGS self, LSET aMask)

Definition at line 11304 of file pcbnew.py.

◆ SetGridOrigin()

def pcbnew.BOARD_DESIGN_SETTINGS.SetGridOrigin	(	self,
		aOrigin
	)

SetGridOrigin(BOARD_DESIGN_SETTINGS self, VECTOR2I aOrigin)

Definition at line 11376 of file pcbnew.py.

◆ SetTrackWidthIndex()

def pcbnew.BOARD_DESIGN_SETTINGS.SetTrackWidthIndex	(	self,
		aIndex
	)

SetTrackWidthIndex(BOARD_DESIGN_SETTINGS self, unsigned int aIndex)

Definition at line 11194 of file pcbnew.py.

◆ SetUserDefinedLayerCount()

def pcbnew.BOARD_DESIGN_SETTINGS.SetUserDefinedLayerCount	(	self,
		aNewLayerCount
	)

SetUserDefinedLayerCount(BOARD_DESIGN_SETTINGS self, int aNewLayerCount)

Definition at line 11324 of file pcbnew.py.

◆ SetViaSizeIndex()

def pcbnew.BOARD_DESIGN_SETTINGS.SetViaSizeIndex	(	self,
		aIndex
	)

SetViaSizeIndex(BOARD_DESIGN_SETTINGS self, unsigned int aIndex)

Definition at line 11214 of file pcbnew.py.

◆ UseCustomDiffPairDimensions()

def pcbnew.BOARD_DESIGN_SETTINGS.UseCustomDiffPairDimensions	(		self,
		*	args
	)

    UseCustomDiffPairDimensions(BOARD_DESIGN_SETTINGS self, bool aEnabled)
    UseCustomDiffPairDimensions(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11281 of file pcbnew.py.

Here is the caller graph for this function:

◆ UseCustomTrackViaSize()

def pcbnew.BOARD_DESIGN_SETTINGS.UseCustomTrackViaSize	(		self,
		*	args
	)

    UseCustomTrackViaSize(BOARD_DESIGN_SETTINGS self, bool aEnabled)
    UseCustomTrackViaSize(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11242 of file pcbnew.py.

Here is the caller graph for this function:

◆ UseNetClassDiffPair()

def pcbnew.BOARD_DESIGN_SETTINGS.UseNetClassDiffPair ( self )

UseNetClassDiffPair(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11178 of file pcbnew.py.

◆ UseNetClassTrack()

def pcbnew.BOARD_DESIGN_SETTINGS.UseNetClassTrack ( self )

UseNetClassTrack(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11170 of file pcbnew.py.

◆ UseNetClassVia()

def pcbnew.BOARD_DESIGN_SETTINGS.UseNetClassVia ( self )

UseNetClassVia(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11174 of file pcbnew.py.

Property Documentation

◆ m_AllowSoldermaskBridgesInFPs

property pcbnew.BOARD_DESIGN_SETTINGS.m_AllowSoldermaskBridgesInFPs = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_AllowSoldermaskBridgesInFPs_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_AllowSoldermaskBridgesInFPs_set, doc=)

static

Definition at line 11423 of file pcbnew.py.

◆ m_CapVias

property pcbnew.BOARD_DESIGN_SETTINGS.m_CapVias = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CapVias_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CapVias_set, doc=)

static

Definition at line 11430 of file pcbnew.py.

◆ m_CopperEdgeClearance

property pcbnew.BOARD_DESIGN_SETTINGS.m_CopperEdgeClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CopperEdgeClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CopperEdgeClearance_set, doc=)

static

Definition at line 11406 of file pcbnew.py.

◆ m_CoverViasBack

property pcbnew.BOARD_DESIGN_SETTINGS.m_CoverViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasBack_set, doc=)

static

Definition at line 11427 of file pcbnew.py.

◆ m_CoverViasFront

property pcbnew.BOARD_DESIGN_SETTINGS.m_CoverViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasFront_set, doc=)

static

Definition at line 11426 of file pcbnew.py.

◆ m_CurrentViaType

property pcbnew.BOARD_DESIGN_SETTINGS.m_CurrentViaType = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CurrentViaType_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CurrentViaType_set, doc=)

static

Definition at line 11394 of file pcbnew.py.

◆ m_DefaultFPTextItems

property pcbnew.BOARD_DESIGN_SETTINGS.m_DefaultFPTextItems = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DefaultFPTextItems_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DefaultFPTextItems_set, doc=)

static

Definition at line 11433 of file pcbnew.py.

◆ m_DiffPairDimensionsList

property pcbnew.BOARD_DESIGN_SETTINGS.m_DiffPairDimensionsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairDimensionsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairDimensionsList_set, doc=)

static

Definition at line 11389 of file pcbnew.py.

◆ m_DiffPairMeanderSettings

property pcbnew.BOARD_DESIGN_SETTINGS.m_DiffPairMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairMeanderSettings_set, doc=)

static

Definition at line 11392 of file pcbnew.py.

◆ m_DimensionArrowLength

property pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionArrowLength = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionArrowLength_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionArrowLength_set, doc=)

static

Definition at line 11446 of file pcbnew.py.

◆ m_DimensionExtensionOffset

property pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionExtensionOffset = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionExtensionOffset_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionExtensionOffset_set, doc=)

static

Definition at line 11447 of file pcbnew.py.

◆ m_DimensionKeepTextAligned

property pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionKeepTextAligned = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionKeepTextAligned_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionKeepTextAligned_set, doc=)

static

Definition at line 11445 of file pcbnew.py.

◆ m_DimensionPrecision

property pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionPrecision = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionPrecision_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionPrecision_set, doc=)

static

Definition at line 11441 of file pcbnew.py.

◆ m_DimensionSuppressZeroes

property pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionSuppressZeroes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionSuppressZeroes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionSuppressZeroes_set, doc=)

static

Definition at line 11443 of file pcbnew.py.

◆ m_DimensionTextPosition

property pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionTextPosition = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionTextPosition_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionTextPosition_set, doc=)

static

Definition at line 11444 of file pcbnew.py.

◆ m_DimensionUnitsFormat

property pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionUnitsFormat = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsFormat_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsFormat_set, doc=)

static

Definition at line 11442 of file pcbnew.py.

◆ m_DimensionUnitsMode

property pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionUnitsMode = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsMode_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsMode_set, doc=)

static

Definition at line 11440 of file pcbnew.py.

◆ m_DrcExclusionComments

property pcbnew.BOARD_DESIGN_SETTINGS.m_DrcExclusionComments = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusionComments_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusionComments_set, doc=)

static

Definition at line 11415 of file pcbnew.py.

◆ m_DrcExclusions

property pcbnew.BOARD_DESIGN_SETTINGS.m_DrcExclusions = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusions_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusions_set, doc=)

static

Definition at line 11414 of file pcbnew.py.

◆ m_DRCSeverities

property pcbnew.BOARD_DESIGN_SETTINGS.m_DRCSeverities = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DRCSeverities_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DRCSeverities_set, doc=)

static

Definition at line 11413 of file pcbnew.py.

◆ m_FillVias

property pcbnew.BOARD_DESIGN_SETTINGS.m_FillVias = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_FillVias_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_FillVias_set, doc=)

static

Definition at line 11431 of file pcbnew.py.

◆ m_HasStackup

property pcbnew.BOARD_DESIGN_SETTINGS.m_HasStackup = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HasStackup_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HasStackup_set, doc=)

static

Definition at line 11451 of file pcbnew.py.

◆ m_HoleClearance

property pcbnew.BOARD_DESIGN_SETTINGS.m_HoleClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HoleClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HoleClearance_set, doc=)

static

Definition at line 11407 of file pcbnew.py.

◆ m_HoleToHoleMin

property pcbnew.BOARD_DESIGN_SETTINGS.m_HoleToHoleMin = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HoleToHoleMin_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HoleToHoleMin_set, doc=)

static

Definition at line 11408 of file pcbnew.py.

◆ m_LineThickness

property pcbnew.BOARD_DESIGN_SETTINGS.m_LineThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_LineThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_LineThickness_set, doc=)

static

Definition at line 11435 of file pcbnew.py.

◆ m_MaxError

property pcbnew.BOARD_DESIGN_SETTINGS.m_MaxError = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MaxError_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MaxError_set, doc=)

static

Definition at line 11417 of file pcbnew.py.

◆ m_MicroViasMinDrill

property pcbnew.BOARD_DESIGN_SETTINGS.m_MicroViasMinDrill = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinDrill_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinDrill_set, doc=)

static

Definition at line 11405 of file pcbnew.py.

◆ m_MicroViasMinSize

property pcbnew.BOARD_DESIGN_SETTINGS.m_MicroViasMinSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinSize_set, doc=)

static

Definition at line 11404 of file pcbnew.py.

◆ m_MinClearance

property pcbnew.BOARD_DESIGN_SETTINGS.m_MinClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinClearance_set, doc=)

static

Definition at line 11397 of file pcbnew.py.

◆ m_MinConn

property pcbnew.BOARD_DESIGN_SETTINGS.m_MinConn = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinConn_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinConn_set, doc=)

static

Definition at line 11399 of file pcbnew.py.

◆ m_MinGrooveWidth

property pcbnew.BOARD_DESIGN_SETTINGS.m_MinGrooveWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinGrooveWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinGrooveWidth_set, doc=)

static

Definition at line 11398 of file pcbnew.py.

◆ m_MinResolvedSpokes

property pcbnew.BOARD_DESIGN_SETTINGS.m_MinResolvedSpokes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinResolvedSpokes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinResolvedSpokes_set, doc=)

static

Definition at line 11410 of file pcbnew.py.

◆ m_MinSilkTextHeight

property pcbnew.BOARD_DESIGN_SETTINGS.m_MinSilkTextHeight = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextHeight_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextHeight_set, doc=)

static

Definition at line 11411 of file pcbnew.py.

◆ m_MinSilkTextThickness

property pcbnew.BOARD_DESIGN_SETTINGS.m_MinSilkTextThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextThickness_set, doc=)

static

Definition at line 11412 of file pcbnew.py.

◆ m_MinThroughDrill

property pcbnew.BOARD_DESIGN_SETTINGS.m_MinThroughDrill = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinThroughDrill_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinThroughDrill_set, doc=)

static

Definition at line 11403 of file pcbnew.py.

◆ m_NetSettings

property pcbnew.BOARD_DESIGN_SETTINGS.m_NetSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_NetSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_NetSettings_set, doc=)

static

Definition at line 11432 of file pcbnew.py.

◆ m_PlugViasBack

property pcbnew.BOARD_DESIGN_SETTINGS.m_PlugViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasBack_set, doc=)

static

Definition at line 11429 of file pcbnew.py.

◆ m_PlugViasFront

property pcbnew.BOARD_DESIGN_SETTINGS.m_PlugViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasFront_set, doc=)

static

Definition at line 11428 of file pcbnew.py.

◆ m_SilkClearance

property pcbnew.BOARD_DESIGN_SETTINGS.m_SilkClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SilkClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SilkClearance_set, doc=)

static

Definition at line 11409 of file pcbnew.py.

◆ m_SingleTrackMeanderSettings

property pcbnew.BOARD_DESIGN_SETTINGS.m_SingleTrackMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SingleTrackMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SingleTrackMeanderSettings_set, doc=)

static

Definition at line 11391 of file pcbnew.py.

◆ m_SkewMeanderSettings

property pcbnew.BOARD_DESIGN_SETTINGS.m_SkewMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SkewMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SkewMeanderSettings_set, doc=)

static

Definition at line 11393 of file pcbnew.py.

◆ m_SolderMaskExpansion

property pcbnew.BOARD_DESIGN_SETTINGS.m_SolderMaskExpansion = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskExpansion_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskExpansion_set, doc=)

static

Definition at line 11418 of file pcbnew.py.

◆ m_SolderMaskMinWidth

property pcbnew.BOARD_DESIGN_SETTINGS.m_SolderMaskMinWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskMinWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskMinWidth_set, doc=)

static

Definition at line 11419 of file pcbnew.py.

◆ m_SolderMaskToCopperClearance

property pcbnew.BOARD_DESIGN_SETTINGS.m_SolderMaskToCopperClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskToCopperClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskToCopperClearance_set, doc=)

static

Definition at line 11420 of file pcbnew.py.

◆ m_SolderPasteMargin

property pcbnew.BOARD_DESIGN_SETTINGS.m_SolderPasteMargin = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMargin_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMargin_set, doc=)

static

Definition at line 11421 of file pcbnew.py.

◆ m_SolderPasteMarginRatio

property pcbnew.BOARD_DESIGN_SETTINGS.m_SolderPasteMarginRatio = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMarginRatio_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMarginRatio_set, doc=)

static

Definition at line 11422 of file pcbnew.py.

◆ m_StyleFPFields

property pcbnew.BOARD_DESIGN_SETTINGS.m_StyleFPFields = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPFields_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPFields_set, doc=)

static

Definition at line 11448 of file pcbnew.py.

◆ m_StyleFPShapes

property pcbnew.BOARD_DESIGN_SETTINGS.m_StyleFPShapes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPShapes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPShapes_set, doc=)

static

Definition at line 11450 of file pcbnew.py.

◆ m_StyleFPText

property pcbnew.BOARD_DESIGN_SETTINGS.m_StyleFPText = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPText_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPText_set, doc=)

static

Definition at line 11449 of file pcbnew.py.

◆ m_TeardropParamsList

property pcbnew.BOARD_DESIGN_SETTINGS.m_TeardropParamsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TeardropParamsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TeardropParamsList_set, doc=)

static

Definition at line 11390 of file pcbnew.py.

◆ m_TempOverrideTrackWidth

property pcbnew.BOARD_DESIGN_SETTINGS.m_TempOverrideTrackWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TempOverrideTrackWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TempOverrideTrackWidth_set, doc=)

static

Definition at line 11396 of file pcbnew.py.

◆ m_TentViasBack

property pcbnew.BOARD_DESIGN_SETTINGS.m_TentViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasBack_set, doc=)

static

Definition at line 11425 of file pcbnew.py.

◆ m_TentViasFront

property pcbnew.BOARD_DESIGN_SETTINGS.m_TentViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasFront_set, doc=)

static

Definition at line 11424 of file pcbnew.py.

◆ m_TextItalic

property pcbnew.BOARD_DESIGN_SETTINGS.m_TextItalic = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextItalic_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextItalic_set, doc=)

static

Definition at line 11438 of file pcbnew.py.

◆ m_TextSize

property pcbnew.BOARD_DESIGN_SETTINGS.m_TextSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextSize_set, doc=)

static

Definition at line 11436 of file pcbnew.py.

◆ m_TextThickness

property pcbnew.BOARD_DESIGN_SETTINGS.m_TextThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextThickness_set, doc=)

static

Definition at line 11437 of file pcbnew.py.

◆ m_TextUpright

property pcbnew.BOARD_DESIGN_SETTINGS.m_TextUpright = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextUpright_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextUpright_set, doc=)

static

Definition at line 11439 of file pcbnew.py.

◆ m_TrackMinWidth

property pcbnew.BOARD_DESIGN_SETTINGS.m_TrackMinWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TrackMinWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TrackMinWidth_set, doc=)

static

Definition at line 11400 of file pcbnew.py.

◆ m_TrackWidthList

property pcbnew.BOARD_DESIGN_SETTINGS.m_TrackWidthList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TrackWidthList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TrackWidthList_set, doc=)

static

Definition at line 11387 of file pcbnew.py.

◆ m_UseConnectedTrackWidth

property pcbnew.BOARD_DESIGN_SETTINGS.m_UseConnectedTrackWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UseConnectedTrackWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UseConnectedTrackWidth_set, doc=)

static

Definition at line 11395 of file pcbnew.py.

◆ m_UseHeightForLengthCalcs

property pcbnew.BOARD_DESIGN_SETTINGS.m_UseHeightForLengthCalcs = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UseHeightForLengthCalcs_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UseHeightForLengthCalcs_set, doc=)

static

Definition at line 11452 of file pcbnew.py.

◆ m_UserLayerNames

property pcbnew.BOARD_DESIGN_SETTINGS.m_UserLayerNames = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UserLayerNames_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UserLayerNames_set, doc=)

static

Definition at line 11434 of file pcbnew.py.

◆ m_ViasDimensionsList

property pcbnew.BOARD_DESIGN_SETTINGS.m_ViasDimensionsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasDimensionsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasDimensionsList_set, doc=)

static

Definition at line 11388 of file pcbnew.py.

◆ m_ViasMinAnnularWidth

property pcbnew.BOARD_DESIGN_SETTINGS.m_ViasMinAnnularWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinAnnularWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinAnnularWidth_set, doc=)

static

Definition at line 11401 of file pcbnew.py.

◆ m_ViasMinSize

property pcbnew.BOARD_DESIGN_SETTINGS.m_ViasMinSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinSize_set, doc=)

static

Definition at line 11402 of file pcbnew.py.

◆ m_ZoneKeepExternalFillets

property pcbnew.BOARD_DESIGN_SETTINGS.m_ZoneKeepExternalFillets = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneKeepExternalFillets_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneKeepExternalFillets_set, doc=)

static

Definition at line 11416 of file pcbnew.py.

◆ thisown

property pcbnew.BOARD_DESIGN_SETTINGS.thisown = property(lambda x: x.this.own(), lambda x, v: x.this.own(v), doc="The membership flag")

static

Definition at line 11116 of file pcbnew.py.

The documentation for this class was generated from the following file:

pcbnew.py

Public Member Functions

Properties

Detailed Description

Constructor & Destructor Documentation

◆ __init__()

Member Function Documentation

◆ __eq__()

◆ __ne__()

◆ CloneFrom()

◆ GetAuxOrigin()

◆ GetBiggestClearanceValue()

◆ GetBoardThickness()

◆ GetCopperLayerCount()

◆ GetCurrentDiffPairGap()

◆ GetCurrentDiffPairViaGap()

◆ GetCurrentDiffPairWidth()

◆ GetCurrentNetClassName()

◆ GetCurrentTrackWidth()

◆ GetCurrentViaDrill()

◆ GetCurrentViaSize()

◆ GetCustomDiffPairGap()

◆ GetCustomDiffPairViaGap()

◆ GetCustomDiffPairWidth()

◆ GetCustomTrackWidth()

◆ GetCustomViaDrill()

◆ GetCustomViaSize()

◆ GetDefaultZoneSettings()

◆ GetDiffPairIndex()

◆ GetDRCEpsilon()

◆ GetEnabledLayers()

◆ GetGridOrigin()

◆ GetHolePlatingThickness()

◆ GetLayerClass()

◆ GetLineThickness()

◆ GetSeverity()

◆ GetSmallestClearanceValue()

◆ GetStackupDescriptor()

◆ GetTeadropParamsList()

◆ GetTextItalic()

◆ GetTextSize()

◆ GetTextThickness()

◆ GetTextUpright()

◆ GetTrackWidthIndex()

◆ GetUserDefinedLayerCount()

◆ GetViaSizeIndex()

◆ Ignore()

◆ IsLayerEnabled()

◆ LoadFromFile()

◆ SetAuxOrigin()

◆ SetBoardThickness()

◆ SetCopperLayerCount()

◆ SetCustomDiffPairGap()

◆ SetCustomDiffPairViaGap()

◆ SetCustomDiffPairWidth()

◆ SetCustomTrackWidth()

◆ SetCustomViaDrill()

◆ SetCustomViaSize()

◆ SetDefaultMasterPad()

◆ SetDefaultZoneSettings()

◆ SetDiffPairIndex()

◆ SetEnabledLayers()

◆ SetGridOrigin()

◆ SetTrackWidthIndex()

◆ SetUserDefinedLayerCount()

◆ SetViaSizeIndex()

◆ UseCustomDiffPairDimensions()

◆ UseCustomTrackViaSize()

◆ UseNetClassDiffPair()

◆ UseNetClassTrack()

◆ UseNetClassVia()

Property Documentation

◆ m_AllowSoldermaskBridgesInFPs

◆ m_CapVias

◆ m_CopperEdgeClearance

◆ m_CoverViasBack

◆ m_CoverViasFront

◆ m_CurrentViaType

◆ m_DefaultFPTextItems

◆ m_DiffPairDimensionsList

◆ m_DiffPairMeanderSettings

◆ init()

◆ eq()

◆ ne()
