Inheritance diagram for pcbnew.BOARD_DESIGN_SETTINGS:

Public Member Functions
	__eq__ (self, aOther)

	__ne__ (self, aOther)

	__init__ (self, *args)

	LoadFromFile (self, *args)

	GetStackupDescriptor (self, *args)

	GetTeadropParamsList (self)

	GetSeverity (self, aDRCErrorCode)

	Ignore (self, aDRCErrorCode)

	GetDefaultZoneSettings (self)

	SetDefaultZoneSettings (self, aSettings)

	GetCurrentNetClassName (self)

	UseNetClassTrack (self)

	UseNetClassVia (self)

	UseNetClassDiffPair (self)

	GetBiggestClearanceValue (self)

	GetSmallestClearanceValue (self)

	GetTrackWidthIndex (self)

	SetTrackWidthIndex (self, aIndex)

	GetCurrentTrackWidth (self)

	SetCustomTrackWidth (self, aWidth)

	GetCustomTrackWidth (self)

	GetViaSizeIndex (self)

	SetViaSizeIndex (self, aIndex)

	GetCurrentViaSize (self)

	SetCustomViaSize (self, aSize)

	GetCustomViaSize (self)

	GetCurrentViaDrill (self)

	SetCustomViaDrill (self, aDrill)

	GetCustomViaDrill (self)

	UseCustomTrackViaSize (self, *args)

	GetDiffPairIndex (self)

	SetDiffPairIndex (self, aIndex)

	SetCustomDiffPairWidth (self, aWidth)

	GetCustomDiffPairWidth (self)

	SetCustomDiffPairGap (self, aGap)

	GetCustomDiffPairGap (self)

	SetCustomDiffPairViaGap (self, aGap)

	GetCustomDiffPairViaGap (self)

	UseCustomDiffPairDimensions (self, *args)

	GetCurrentDiffPairWidth (self)

	GetCurrentDiffPairGap (self)

	GetCurrentDiffPairViaGap (self)

	GetEnabledLayers (self)

	SetEnabledLayers (self, aMask)

	IsLayerEnabled (self, aLayerId)

	GetCopperLayerCount (self)

	SetCopperLayerCount (self, aNewLayerCount)

	GetUserDefinedLayerCount (self)

	SetUserDefinedLayerCount (self, aNewLayerCount)

	GetBoardThickness (self)

	SetBoardThickness (self, aThickness)

	GetDRCEpsilon (self)

	GetHolePlatingThickness (self)

	GetLineThickness (self, aLayer)

	GetTextSize (self, aLayer)

	GetTextThickness (self, aLayer)

	GetTextItalic (self, aLayer)

	GetTextUpright (self, aLayer)

	GetLayerClass (self, aLayer)

	SetAuxOrigin (self, aOrigin)

	GetAuxOrigin (self)

	SetGridOrigin (self, aOrigin)

	GetGridOrigin (self)

	SetDefaultMasterPad (self)

	CloneFrom (self, aOther)

Properties
	thisown = property(lambda x: x.this.own(), lambda x, v: x.this.own(v), doc="The membership flag")

	m_TrackWidthList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TrackWidthList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TrackWidthList_set, doc=)

	m_ViasDimensionsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasDimensionsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasDimensionsList_set, doc=)

	m_DiffPairDimensionsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairDimensionsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairDimensionsList_set, doc=)

	m_TeardropParamsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TeardropParamsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TeardropParamsList_set, doc=)

	m_SingleTrackMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SingleTrackMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SingleTrackMeanderSettings_set, doc=)

	m_DiffPairMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairMeanderSettings_set, doc=)

	m_SkewMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SkewMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SkewMeanderSettings_set, doc=)

	m_CurrentViaType = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CurrentViaType_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CurrentViaType_set, doc=)

	m_UseConnectedTrackWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UseConnectedTrackWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UseConnectedTrackWidth_set, doc=)

	m_TempOverrideTrackWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TempOverrideTrackWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TempOverrideTrackWidth_set, doc=)

	m_MinClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinClearance_set, doc=)

	m_MinGrooveWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinGrooveWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinGrooveWidth_set, doc=)

	m_MinConn = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinConn_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinConn_set, doc=)

	m_TrackMinWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TrackMinWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TrackMinWidth_set, doc=)

	m_ViasMinAnnularWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinAnnularWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinAnnularWidth_set, doc=)

	m_ViasMinSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinSize_set, doc=)

	m_MinThroughDrill = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinThroughDrill_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinThroughDrill_set, doc=)

	m_MicroViasMinSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinSize_set, doc=)

	m_MicroViasMinDrill = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinDrill_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinDrill_set, doc=)

	m_CopperEdgeClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CopperEdgeClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CopperEdgeClearance_set, doc=)

	m_HoleClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HoleClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HoleClearance_set, doc=)

	m_HoleToHoleMin = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HoleToHoleMin_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HoleToHoleMin_set, doc=)

	m_SilkClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SilkClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SilkClearance_set, doc=)

	m_MinResolvedSpokes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinResolvedSpokes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinResolvedSpokes_set, doc=)

	m_MinSilkTextHeight = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextHeight_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextHeight_set, doc=)

	m_MinSilkTextThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextThickness_set, doc=)

	m_DRCSeverities = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DRCSeverities_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DRCSeverities_set, doc=)

	m_DrcExclusions = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusions_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusions_set, doc=)

	m_DrcExclusionComments = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusionComments_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusionComments_set, doc=)

	m_ZoneKeepExternalFillets = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneKeepExternalFillets_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneKeepExternalFillets_set, doc=)

	m_MaxError = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MaxError_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MaxError_set, doc=)

	m_SolderMaskExpansion = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskExpansion_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskExpansion_set, doc=)

	m_SolderMaskMinWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskMinWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskMinWidth_set, doc=)

	m_SolderMaskToCopperClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskToCopperClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskToCopperClearance_set, doc=)

	m_SolderPasteMargin = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMargin_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMargin_set, doc=)

	m_SolderPasteMarginRatio = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMarginRatio_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMarginRatio_set, doc=)

	m_AllowSoldermaskBridgesInFPs = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_AllowSoldermaskBridgesInFPs_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_AllowSoldermaskBridgesInFPs_set, doc=)

	m_TentViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasFront_set, doc=)

	m_TentViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasBack_set, doc=)

	m_CoverViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasFront_set, doc=)

	m_CoverViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasBack_set, doc=)

	m_PlugViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasFront_set, doc=)

	m_PlugViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasBack_set, doc=)

	m_CapVias = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CapVias_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CapVias_set, doc=)

	m_FillVias = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_FillVias_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_FillVias_set, doc=)

	m_NetSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_NetSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_NetSettings_set, doc=)

	m_DefaultFPTextItems = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DefaultFPTextItems_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DefaultFPTextItems_set, doc=)

	m_UserLayerNames = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UserLayerNames_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UserLayerNames_set, doc=)

	m_ZoneLayerProperties = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneLayerProperties_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneLayerProperties_set, doc=)

	m_LineThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_LineThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_LineThickness_set, doc=)

	m_TextSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextSize_set, doc=)

	m_TextThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextThickness_set, doc=)

	m_TextItalic = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextItalic_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextItalic_set, doc=)

	m_TextUpright = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextUpright_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextUpright_set, doc=)

	m_DimensionUnitsMode = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsMode_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsMode_set, doc=)

	m_DimensionPrecision = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionPrecision_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionPrecision_set, doc=)

	m_DimensionUnitsFormat = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsFormat_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsFormat_set, doc=)

	m_DimensionSuppressZeroes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionSuppressZeroes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionSuppressZeroes_set, doc=)

	m_DimensionTextPosition = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionTextPosition_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionTextPosition_set, doc=)

	m_DimensionKeepTextAligned = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionKeepTextAligned_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionKeepTextAligned_set, doc=)

	m_DimensionArrowLength = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionArrowLength_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionArrowLength_set, doc=)

	m_DimensionExtensionOffset = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionExtensionOffset_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionExtensionOffset_set, doc=)

	m_StyleFPFields = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPFields_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPFields_set, doc=)

	m_StyleFPText = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPText_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPText_set, doc=)

	m_StyleFPShapes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPShapes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPShapes_set, doc=)

	m_StyleFPDimensions = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPDimensions_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPDimensions_set, doc=)

	m_StyleFPBarcodes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPBarcodes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPBarcodes_set, doc=)

	m_HasStackup = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HasStackup_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HasStackup_set, doc=)

	m_UseHeightForLengthCalcs = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UseHeightForLengthCalcs_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UseHeightForLengthCalcs_set, doc=)

Detailed Description

Proxy of C++ BOARD_DESIGN_SETTINGS class.

Definition at line 11836 of file pcbnew.py.

Constructor & Destructor Documentation

◆ init()

pcbnew.BOARD_DESIGN_SETTINGS.__init__	(		self,
		*	args )

    __init__(BOARD_DESIGN_SETTINGS self, JSON_SETTINGS * aParent, string aPath) -> BOARD_DESIGN_SETTINGS
    __init__(BOARD_DESIGN_SETTINGS self, BOARD_DESIGN_SETTINGS aOther) -> BOARD_DESIGN_SETTINGS

Definition at line 11851 of file pcbnew.py.

Member Function Documentation

◆ eq()

pcbnew.BOARD_DESIGN_SETTINGS.__eq__	(		self,
			aOther )

__eq__(BOARD_DESIGN_SETTINGS self, BOARD_DESIGN_SETTINGS aOther) -> bool

Definition at line 11843 of file pcbnew.py.

◆ ne()

pcbnew.BOARD_DESIGN_SETTINGS.__ne__	(		self,
			aOther )

__ne__(BOARD_DESIGN_SETTINGS self, BOARD_DESIGN_SETTINGS aOther) -> bool

Definition at line 11847 of file pcbnew.py.

◆ CloneFrom()

pcbnew.BOARD_DESIGN_SETTINGS.CloneFrom	(		self,
			aOther )

CloneFrom(BOARD_DESIGN_SETTINGS self, BOARD_DESIGN_SETTINGS aOther)

Definition at line 12180 of file pcbnew.py.

◆ GetAuxOrigin()

pcbnew.BOARD_DESIGN_SETTINGS.GetAuxOrigin ( self )

GetAuxOrigin(BOARD_DESIGN_SETTINGS self) -> VECTOR2I

Definition at line 12095 of file pcbnew.py.

◆ GetBiggestClearanceValue()

pcbnew.BOARD_DESIGN_SETTINGS.GetBiggestClearanceValue ( self )

GetBiggestClearanceValue(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11905 of file pcbnew.py.

◆ GetBoardThickness()

pcbnew.BOARD_DESIGN_SETTINGS.GetBoardThickness ( self )

GetBoardThickness(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12051 of file pcbnew.py.

◆ GetCopperLayerCount()

pcbnew.BOARD_DESIGN_SETTINGS.GetCopperLayerCount ( self )

GetCopperLayerCount(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12035 of file pcbnew.py.

◆ GetCurrentDiffPairGap()

pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentDiffPairGap ( self )

GetCurrentDiffPairGap(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12015 of file pcbnew.py.

◆ GetCurrentDiffPairViaGap()

pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentDiffPairViaGap ( self )

GetCurrentDiffPairViaGap(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12019 of file pcbnew.py.

◆ GetCurrentDiffPairWidth()

pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentDiffPairWidth ( self )

GetCurrentDiffPairWidth(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12011 of file pcbnew.py.

◆ GetCurrentNetClassName()

pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentNetClassName ( self )

GetCurrentNetClassName(BOARD_DESIGN_SETTINGS self) -> wxString

Definition at line 11889 of file pcbnew.py.

◆ GetCurrentTrackWidth()

pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentTrackWidth ( self )

GetCurrentTrackWidth(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11921 of file pcbnew.py.

◆ GetCurrentViaDrill()

pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentViaDrill ( self )

GetCurrentViaDrill(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11953 of file pcbnew.py.

◆ GetCurrentViaSize()

pcbnew.BOARD_DESIGN_SETTINGS.GetCurrentViaSize ( self )

GetCurrentViaSize(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11941 of file pcbnew.py.

◆ GetCustomDiffPairGap()

pcbnew.BOARD_DESIGN_SETTINGS.GetCustomDiffPairGap ( self )

GetCustomDiffPairGap(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11992 of file pcbnew.py.

◆ GetCustomDiffPairViaGap()

pcbnew.BOARD_DESIGN_SETTINGS.GetCustomDiffPairViaGap ( self )

GetCustomDiffPairViaGap(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12000 of file pcbnew.py.

◆ GetCustomDiffPairWidth()

pcbnew.BOARD_DESIGN_SETTINGS.GetCustomDiffPairWidth ( self )

GetCustomDiffPairWidth(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11984 of file pcbnew.py.

◆ GetCustomTrackWidth()

pcbnew.BOARD_DESIGN_SETTINGS.GetCustomTrackWidth ( self )

GetCustomTrackWidth(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11929 of file pcbnew.py.

◆ GetCustomViaDrill()

pcbnew.BOARD_DESIGN_SETTINGS.GetCustomViaDrill ( self )

GetCustomViaDrill(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11961 of file pcbnew.py.

◆ GetCustomViaSize()

pcbnew.BOARD_DESIGN_SETTINGS.GetCustomViaSize ( self )

GetCustomViaSize(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11949 of file pcbnew.py.

◆ GetDefaultZoneSettings()

pcbnew.BOARD_DESIGN_SETTINGS.GetDefaultZoneSettings ( self )

GetDefaultZoneSettings(BOARD_DESIGN_SETTINGS self) -> ZONE_SETTINGS

Definition at line 11881 of file pcbnew.py.

◆ GetDiffPairIndex()

pcbnew.BOARD_DESIGN_SETTINGS.GetDiffPairIndex ( self )

GetDiffPairIndex(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11972 of file pcbnew.py.

◆ GetDRCEpsilon()

pcbnew.BOARD_DESIGN_SETTINGS.GetDRCEpsilon ( self )

GetDRCEpsilon(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12059 of file pcbnew.py.

◆ GetEnabledLayers()

pcbnew.BOARD_DESIGN_SETTINGS.GetEnabledLayers ( self )

GetEnabledLayers(BOARD_DESIGN_SETTINGS self) -> LSET

Definition at line 12023 of file pcbnew.py.

◆ GetGridOrigin()

pcbnew.BOARD_DESIGN_SETTINGS.GetGridOrigin ( self )

GetGridOrigin(BOARD_DESIGN_SETTINGS self) -> VECTOR2I

Definition at line 12103 of file pcbnew.py.

◆ GetHolePlatingThickness()

pcbnew.BOARD_DESIGN_SETTINGS.GetHolePlatingThickness ( self )

GetHolePlatingThickness(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12063 of file pcbnew.py.

◆ GetLayerClass()

pcbnew.BOARD_DESIGN_SETTINGS.GetLayerClass	(		self,
			aLayer )

GetLayerClass(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> int

Definition at line 12087 of file pcbnew.py.

◆ GetLineThickness()

pcbnew.BOARD_DESIGN_SETTINGS.GetLineThickness	(		self,
			aLayer )

GetLineThickness(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> int

Definition at line 12067 of file pcbnew.py.

Here is the caller graph for this function:

◆ GetSeverity()

pcbnew.BOARD_DESIGN_SETTINGS.GetSeverity	(		self,
			aDRCErrorCode )

GetSeverity(BOARD_DESIGN_SETTINGS self, int aDRCErrorCode) -> SEVERITY

Definition at line 11873 of file pcbnew.py.

◆ GetSmallestClearanceValue()

pcbnew.BOARD_DESIGN_SETTINGS.GetSmallestClearanceValue ( self )

GetSmallestClearanceValue(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11909 of file pcbnew.py.

◆ GetStackupDescriptor()

pcbnew.BOARD_DESIGN_SETTINGS.GetStackupDescriptor	(		self,
		*	args )

    GetStackupDescriptor(BOARD_DESIGN_SETTINGS self) -> BOARD_STACKUP
    GetStackupDescriptor(BOARD_DESIGN_SETTINGS self) -> BOARD_STACKUP const &

Definition at line 11862 of file pcbnew.py.

◆ GetTeadropParamsList()

pcbnew.BOARD_DESIGN_SETTINGS.GetTeadropParamsList ( self )

GetTeadropParamsList(BOARD_DESIGN_SETTINGS self) -> TEARDROP_PARAMETERS_LIST *

Definition at line 11869 of file pcbnew.py.

◆ GetTextItalic()

pcbnew.BOARD_DESIGN_SETTINGS.GetTextItalic	(		self,
			aLayer )

GetTextItalic(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> bool

Definition at line 12079 of file pcbnew.py.

◆ GetTextSize()

pcbnew.BOARD_DESIGN_SETTINGS.GetTextSize	(		self,
			aLayer )

GetTextSize(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> VECTOR2I

Definition at line 12071 of file pcbnew.py.

◆ GetTextThickness()

pcbnew.BOARD_DESIGN_SETTINGS.GetTextThickness	(		self,
			aLayer )

GetTextThickness(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> int

Definition at line 12075 of file pcbnew.py.

◆ GetTextUpright()

pcbnew.BOARD_DESIGN_SETTINGS.GetTextUpright	(		self,
			aLayer )

GetTextUpright(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayer) -> bool

Definition at line 12083 of file pcbnew.py.

◆ GetTrackWidthIndex()

pcbnew.BOARD_DESIGN_SETTINGS.GetTrackWidthIndex ( self )

GetTrackWidthIndex(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11913 of file pcbnew.py.

◆ GetUserDefinedLayerCount()

pcbnew.BOARD_DESIGN_SETTINGS.GetUserDefinedLayerCount ( self )

GetUserDefinedLayerCount(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 12043 of file pcbnew.py.

◆ GetViaSizeIndex()

pcbnew.BOARD_DESIGN_SETTINGS.GetViaSizeIndex ( self )

GetViaSizeIndex(BOARD_DESIGN_SETTINGS self) -> int

Definition at line 11933 of file pcbnew.py.

◆ Ignore()

pcbnew.BOARD_DESIGN_SETTINGS.Ignore	(		self,
			aDRCErrorCode )

Ignore(BOARD_DESIGN_SETTINGS self, int aDRCErrorCode) -> bool

Definition at line 11877 of file pcbnew.py.

◆ IsLayerEnabled()

pcbnew.BOARD_DESIGN_SETTINGS.IsLayerEnabled	(		self,
			aLayerId )

IsLayerEnabled(BOARD_DESIGN_SETTINGS self, PCB_LAYER_ID aLayerId) -> bool

Definition at line 12031 of file pcbnew.py.

◆ LoadFromFile()

pcbnew.BOARD_DESIGN_SETTINGS.LoadFromFile	(		self,
		*	args )

LoadFromFile(BOARD_DESIGN_SETTINGS self, wxString aDirectory="") -> bool

Definition at line 11858 of file pcbnew.py.

◆ SetAuxOrigin()

pcbnew.BOARD_DESIGN_SETTINGS.SetAuxOrigin	(		self,
			aOrigin )

SetAuxOrigin(BOARD_DESIGN_SETTINGS self, VECTOR2I aOrigin)

Definition at line 12091 of file pcbnew.py.

◆ SetBoardThickness()

pcbnew.BOARD_DESIGN_SETTINGS.SetBoardThickness	(		self,
			aThickness )

SetBoardThickness(BOARD_DESIGN_SETTINGS self, int aThickness)

Definition at line 12055 of file pcbnew.py.

◆ SetCopperLayerCount()

pcbnew.BOARD_DESIGN_SETTINGS.SetCopperLayerCount	(		self,
			aNewLayerCount )

SetCopperLayerCount(BOARD_DESIGN_SETTINGS self, int aNewLayerCount)

Definition at line 12039 of file pcbnew.py.

◆ SetCustomDiffPairGap()

pcbnew.BOARD_DESIGN_SETTINGS.SetCustomDiffPairGap	(		self,
			aGap )

SetCustomDiffPairGap(BOARD_DESIGN_SETTINGS self, int aGap)

Definition at line 11988 of file pcbnew.py.

◆ SetCustomDiffPairViaGap()

pcbnew.BOARD_DESIGN_SETTINGS.SetCustomDiffPairViaGap	(		self,
			aGap )

SetCustomDiffPairViaGap(BOARD_DESIGN_SETTINGS self, int aGap)

Definition at line 11996 of file pcbnew.py.

◆ SetCustomDiffPairWidth()

pcbnew.BOARD_DESIGN_SETTINGS.SetCustomDiffPairWidth	(		self,
			aWidth )

SetCustomDiffPairWidth(BOARD_DESIGN_SETTINGS self, int aWidth)

Definition at line 11980 of file pcbnew.py.

◆ SetCustomTrackWidth()

pcbnew.BOARD_DESIGN_SETTINGS.SetCustomTrackWidth	(		self,
			aWidth )

SetCustomTrackWidth(BOARD_DESIGN_SETTINGS self, int aWidth)

Definition at line 11925 of file pcbnew.py.

◆ SetCustomViaDrill()

pcbnew.BOARD_DESIGN_SETTINGS.SetCustomViaDrill	(		self,
			aDrill )

SetCustomViaDrill(BOARD_DESIGN_SETTINGS self, int aDrill)

Definition at line 11957 of file pcbnew.py.

◆ SetCustomViaSize()

pcbnew.BOARD_DESIGN_SETTINGS.SetCustomViaSize	(		self,
			aSize )

SetCustomViaSize(BOARD_DESIGN_SETTINGS self, int aSize)

Definition at line 11945 of file pcbnew.py.

◆ SetDefaultMasterPad()

pcbnew.BOARD_DESIGN_SETTINGS.SetDefaultMasterPad ( self )

SetDefaultMasterPad(BOARD_DESIGN_SETTINGS self)

Definition at line 12107 of file pcbnew.py.

◆ SetDefaultZoneSettings()

pcbnew.BOARD_DESIGN_SETTINGS.SetDefaultZoneSettings	(		self,
			aSettings )

SetDefaultZoneSettings(BOARD_DESIGN_SETTINGS self, ZONE_SETTINGS aSettings)

Definition at line 11885 of file pcbnew.py.

◆ SetDiffPairIndex()

pcbnew.BOARD_DESIGN_SETTINGS.SetDiffPairIndex	(		self,
			aIndex )

SetDiffPairIndex(BOARD_DESIGN_SETTINGS self, int aIndex)

Definition at line 11976 of file pcbnew.py.

◆ SetEnabledLayers()

pcbnew.BOARD_DESIGN_SETTINGS.SetEnabledLayers	(		self,
			aMask )

SetEnabledLayers(BOARD_DESIGN_SETTINGS self, LSET aMask)

Definition at line 12027 of file pcbnew.py.

◆ SetGridOrigin()

pcbnew.BOARD_DESIGN_SETTINGS.SetGridOrigin	(		self,
			aOrigin )

SetGridOrigin(BOARD_DESIGN_SETTINGS self, VECTOR2I aOrigin)

Definition at line 12099 of file pcbnew.py.

◆ SetTrackWidthIndex()

pcbnew.BOARD_DESIGN_SETTINGS.SetTrackWidthIndex	(		self,
			aIndex )

SetTrackWidthIndex(BOARD_DESIGN_SETTINGS self, int aIndex)

Definition at line 11917 of file pcbnew.py.

◆ SetUserDefinedLayerCount()

pcbnew.BOARD_DESIGN_SETTINGS.SetUserDefinedLayerCount	(		self,
			aNewLayerCount )

SetUserDefinedLayerCount(BOARD_DESIGN_SETTINGS self, int aNewLayerCount)

Definition at line 12047 of file pcbnew.py.

◆ SetViaSizeIndex()

pcbnew.BOARD_DESIGN_SETTINGS.SetViaSizeIndex	(		self,
			aIndex )

SetViaSizeIndex(BOARD_DESIGN_SETTINGS self, int aIndex)

Definition at line 11937 of file pcbnew.py.

◆ UseCustomDiffPairDimensions()

pcbnew.BOARD_DESIGN_SETTINGS.UseCustomDiffPairDimensions	(		self,
		*	args )

    UseCustomDiffPairDimensions(BOARD_DESIGN_SETTINGS self, bool aEnabled)
    UseCustomDiffPairDimensions(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 12004 of file pcbnew.py.

◆ UseCustomTrackViaSize()

pcbnew.BOARD_DESIGN_SETTINGS.UseCustomTrackViaSize	(		self,
		*	args )

    UseCustomTrackViaSize(BOARD_DESIGN_SETTINGS self, bool aEnabled)
    UseCustomTrackViaSize(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11965 of file pcbnew.py.

◆ UseNetClassDiffPair()

pcbnew.BOARD_DESIGN_SETTINGS.UseNetClassDiffPair ( self )

UseNetClassDiffPair(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11901 of file pcbnew.py.

◆ UseNetClassTrack()

pcbnew.BOARD_DESIGN_SETTINGS.UseNetClassTrack ( self )

UseNetClassTrack(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11893 of file pcbnew.py.

◆ UseNetClassVia()

pcbnew.BOARD_DESIGN_SETTINGS.UseNetClassVia ( self )

UseNetClassVia(BOARD_DESIGN_SETTINGS self) -> bool

Definition at line 11897 of file pcbnew.py.

Property Documentation

◆ m_AllowSoldermaskBridgesInFPs

pcbnew.BOARD_DESIGN_SETTINGS.m_AllowSoldermaskBridgesInFPs = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_AllowSoldermaskBridgesInFPs_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_AllowSoldermaskBridgesInFPs_set, doc=)

static

Definition at line 12146 of file pcbnew.py.

◆ m_CapVias

pcbnew.BOARD_DESIGN_SETTINGS.m_CapVias = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CapVias_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CapVias_set, doc=)

static

Definition at line 12153 of file pcbnew.py.

◆ m_CopperEdgeClearance

pcbnew.BOARD_DESIGN_SETTINGS.m_CopperEdgeClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CopperEdgeClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CopperEdgeClearance_set, doc=)

static

Definition at line 12129 of file pcbnew.py.

◆ m_CoverViasBack

pcbnew.BOARD_DESIGN_SETTINGS.m_CoverViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasBack_set, doc=)

static

Definition at line 12150 of file pcbnew.py.

◆ m_CoverViasFront

pcbnew.BOARD_DESIGN_SETTINGS.m_CoverViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CoverViasFront_set, doc=)

static

Definition at line 12149 of file pcbnew.py.

◆ m_CurrentViaType

pcbnew.BOARD_DESIGN_SETTINGS.m_CurrentViaType = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_CurrentViaType_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_CurrentViaType_set, doc=)

static

Definition at line 12117 of file pcbnew.py.

◆ m_DefaultFPTextItems

pcbnew.BOARD_DESIGN_SETTINGS.m_DefaultFPTextItems = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DefaultFPTextItems_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DefaultFPTextItems_set, doc=)

static

Definition at line 12156 of file pcbnew.py.

◆ m_DiffPairDimensionsList

pcbnew.BOARD_DESIGN_SETTINGS.m_DiffPairDimensionsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairDimensionsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairDimensionsList_set, doc=)

static

Definition at line 12112 of file pcbnew.py.

◆ m_DiffPairMeanderSettings

pcbnew.BOARD_DESIGN_SETTINGS.m_DiffPairMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DiffPairMeanderSettings_set, doc=)

static

Definition at line 12115 of file pcbnew.py.

◆ m_DimensionArrowLength

pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionArrowLength = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionArrowLength_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionArrowLength_set, doc=)

static

Definition at line 12170 of file pcbnew.py.

◆ m_DimensionExtensionOffset

pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionExtensionOffset = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionExtensionOffset_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionExtensionOffset_set, doc=)

static

Definition at line 12171 of file pcbnew.py.

◆ m_DimensionKeepTextAligned

pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionKeepTextAligned = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionKeepTextAligned_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionKeepTextAligned_set, doc=)

static

Definition at line 12169 of file pcbnew.py.

◆ m_DimensionPrecision

pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionPrecision = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionPrecision_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionPrecision_set, doc=)

static

Definition at line 12165 of file pcbnew.py.

◆ m_DimensionSuppressZeroes

pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionSuppressZeroes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionSuppressZeroes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionSuppressZeroes_set, doc=)

static

Definition at line 12167 of file pcbnew.py.

◆ m_DimensionTextPosition

pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionTextPosition = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionTextPosition_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionTextPosition_set, doc=)

static

Definition at line 12168 of file pcbnew.py.

◆ m_DimensionUnitsFormat

pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionUnitsFormat = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsFormat_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsFormat_set, doc=)

static

Definition at line 12166 of file pcbnew.py.

◆ m_DimensionUnitsMode

pcbnew.BOARD_DESIGN_SETTINGS.m_DimensionUnitsMode = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsMode_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DimensionUnitsMode_set, doc=)

static

Definition at line 12164 of file pcbnew.py.

◆ m_DrcExclusionComments

pcbnew.BOARD_DESIGN_SETTINGS.m_DrcExclusionComments = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusionComments_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusionComments_set, doc=)

static

Definition at line 12138 of file pcbnew.py.

◆ m_DrcExclusions

pcbnew.BOARD_DESIGN_SETTINGS.m_DrcExclusions = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusions_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DrcExclusions_set, doc=)

static

Definition at line 12137 of file pcbnew.py.

◆ m_DRCSeverities

pcbnew.BOARD_DESIGN_SETTINGS.m_DRCSeverities = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_DRCSeverities_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_DRCSeverities_set, doc=)

static

Definition at line 12136 of file pcbnew.py.

◆ m_FillVias

pcbnew.BOARD_DESIGN_SETTINGS.m_FillVias = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_FillVias_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_FillVias_set, doc=)

static

Definition at line 12154 of file pcbnew.py.

◆ m_HasStackup

pcbnew.BOARD_DESIGN_SETTINGS.m_HasStackup = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HasStackup_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HasStackup_set, doc=)

static

Definition at line 12177 of file pcbnew.py.

◆ m_HoleClearance

pcbnew.BOARD_DESIGN_SETTINGS.m_HoleClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HoleClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HoleClearance_set, doc=)

static

Definition at line 12130 of file pcbnew.py.

◆ m_HoleToHoleMin

pcbnew.BOARD_DESIGN_SETTINGS.m_HoleToHoleMin = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_HoleToHoleMin_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_HoleToHoleMin_set, doc=)

static

Definition at line 12131 of file pcbnew.py.

◆ m_LineThickness

pcbnew.BOARD_DESIGN_SETTINGS.m_LineThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_LineThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_LineThickness_set, doc=)

static

Definition at line 12159 of file pcbnew.py.

◆ m_MaxError

pcbnew.BOARD_DESIGN_SETTINGS.m_MaxError = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MaxError_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MaxError_set, doc=)

static

Definition at line 12140 of file pcbnew.py.

◆ m_MicroViasMinDrill

pcbnew.BOARD_DESIGN_SETTINGS.m_MicroViasMinDrill = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinDrill_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinDrill_set, doc=)

static

Definition at line 12128 of file pcbnew.py.

◆ m_MicroViasMinSize

pcbnew.BOARD_DESIGN_SETTINGS.m_MicroViasMinSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MicroViasMinSize_set, doc=)

static

Definition at line 12127 of file pcbnew.py.

◆ m_MinClearance

pcbnew.BOARD_DESIGN_SETTINGS.m_MinClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinClearance_set, doc=)

static

Definition at line 12120 of file pcbnew.py.

◆ m_MinConn

pcbnew.BOARD_DESIGN_SETTINGS.m_MinConn = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinConn_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinConn_set, doc=)

static

Definition at line 12122 of file pcbnew.py.

◆ m_MinGrooveWidth

pcbnew.BOARD_DESIGN_SETTINGS.m_MinGrooveWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinGrooveWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinGrooveWidth_set, doc=)

static

Definition at line 12121 of file pcbnew.py.

◆ m_MinResolvedSpokes

pcbnew.BOARD_DESIGN_SETTINGS.m_MinResolvedSpokes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinResolvedSpokes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinResolvedSpokes_set, doc=)

static

Definition at line 12133 of file pcbnew.py.

◆ m_MinSilkTextHeight

pcbnew.BOARD_DESIGN_SETTINGS.m_MinSilkTextHeight = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextHeight_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextHeight_set, doc=)

static

Definition at line 12134 of file pcbnew.py.

◆ m_MinSilkTextThickness

pcbnew.BOARD_DESIGN_SETTINGS.m_MinSilkTextThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinSilkTextThickness_set, doc=)

static

Definition at line 12135 of file pcbnew.py.

◆ m_MinThroughDrill

pcbnew.BOARD_DESIGN_SETTINGS.m_MinThroughDrill = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_MinThroughDrill_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_MinThroughDrill_set, doc=)

static

Definition at line 12126 of file pcbnew.py.

◆ m_NetSettings

pcbnew.BOARD_DESIGN_SETTINGS.m_NetSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_NetSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_NetSettings_set, doc=)

static

Definition at line 12155 of file pcbnew.py.

◆ m_PlugViasBack

pcbnew.BOARD_DESIGN_SETTINGS.m_PlugViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasBack_set, doc=)

static

Definition at line 12152 of file pcbnew.py.

◆ m_PlugViasFront

pcbnew.BOARD_DESIGN_SETTINGS.m_PlugViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_PlugViasFront_set, doc=)

static

Definition at line 12151 of file pcbnew.py.

◆ m_SilkClearance

pcbnew.BOARD_DESIGN_SETTINGS.m_SilkClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SilkClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SilkClearance_set, doc=)

static

Definition at line 12132 of file pcbnew.py.

◆ m_SingleTrackMeanderSettings

pcbnew.BOARD_DESIGN_SETTINGS.m_SingleTrackMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SingleTrackMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SingleTrackMeanderSettings_set, doc=)

static

Definition at line 12114 of file pcbnew.py.

◆ m_SkewMeanderSettings

pcbnew.BOARD_DESIGN_SETTINGS.m_SkewMeanderSettings = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SkewMeanderSettings_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SkewMeanderSettings_set, doc=)

static

Definition at line 12116 of file pcbnew.py.

◆ m_SolderMaskExpansion

pcbnew.BOARD_DESIGN_SETTINGS.m_SolderMaskExpansion = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskExpansion_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskExpansion_set, doc=)

static

Definition at line 12141 of file pcbnew.py.

◆ m_SolderMaskMinWidth

pcbnew.BOARD_DESIGN_SETTINGS.m_SolderMaskMinWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskMinWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskMinWidth_set, doc=)

static

Definition at line 12142 of file pcbnew.py.

◆ m_SolderMaskToCopperClearance

pcbnew.BOARD_DESIGN_SETTINGS.m_SolderMaskToCopperClearance = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskToCopperClearance_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderMaskToCopperClearance_set, doc=)

static

Definition at line 12143 of file pcbnew.py.

◆ m_SolderPasteMargin

pcbnew.BOARD_DESIGN_SETTINGS.m_SolderPasteMargin = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMargin_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMargin_set, doc=)

static

Definition at line 12144 of file pcbnew.py.

◆ m_SolderPasteMarginRatio

pcbnew.BOARD_DESIGN_SETTINGS.m_SolderPasteMarginRatio = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMarginRatio_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_SolderPasteMarginRatio_set, doc=)

static

Definition at line 12145 of file pcbnew.py.

◆ m_StyleFPBarcodes

pcbnew.BOARD_DESIGN_SETTINGS.m_StyleFPBarcodes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPBarcodes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPBarcodes_set, doc=)

static

Definition at line 12176 of file pcbnew.py.

◆ m_StyleFPDimensions

pcbnew.BOARD_DESIGN_SETTINGS.m_StyleFPDimensions = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPDimensions_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPDimensions_set, doc=)

static

Definition at line 12175 of file pcbnew.py.

◆ m_StyleFPFields

pcbnew.BOARD_DESIGN_SETTINGS.m_StyleFPFields = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPFields_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPFields_set, doc=)

static

Definition at line 12172 of file pcbnew.py.

◆ m_StyleFPShapes

pcbnew.BOARD_DESIGN_SETTINGS.m_StyleFPShapes = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPShapes_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPShapes_set, doc=)

static

Definition at line 12174 of file pcbnew.py.

◆ m_StyleFPText

pcbnew.BOARD_DESIGN_SETTINGS.m_StyleFPText = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPText_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_StyleFPText_set, doc=)

static

Definition at line 12173 of file pcbnew.py.

◆ m_TeardropParamsList

pcbnew.BOARD_DESIGN_SETTINGS.m_TeardropParamsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TeardropParamsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TeardropParamsList_set, doc=)

static

Definition at line 12113 of file pcbnew.py.

◆ m_TempOverrideTrackWidth

pcbnew.BOARD_DESIGN_SETTINGS.m_TempOverrideTrackWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TempOverrideTrackWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TempOverrideTrackWidth_set, doc=)

static

Definition at line 12119 of file pcbnew.py.

◆ m_TentViasBack

pcbnew.BOARD_DESIGN_SETTINGS.m_TentViasBack = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasBack_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasBack_set, doc=)

static

Definition at line 12148 of file pcbnew.py.

◆ m_TentViasFront

pcbnew.BOARD_DESIGN_SETTINGS.m_TentViasFront = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasFront_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TentViasFront_set, doc=)

static

Definition at line 12147 of file pcbnew.py.

◆ m_TextItalic

pcbnew.BOARD_DESIGN_SETTINGS.m_TextItalic = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextItalic_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextItalic_set, doc=)

static

Definition at line 12162 of file pcbnew.py.

◆ m_TextSize

pcbnew.BOARD_DESIGN_SETTINGS.m_TextSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextSize_set, doc=)

static

Definition at line 12160 of file pcbnew.py.

◆ m_TextThickness

pcbnew.BOARD_DESIGN_SETTINGS.m_TextThickness = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextThickness_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextThickness_set, doc=)

static

Definition at line 12161 of file pcbnew.py.

◆ m_TextUpright

pcbnew.BOARD_DESIGN_SETTINGS.m_TextUpright = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TextUpright_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TextUpright_set, doc=)

static

Definition at line 12163 of file pcbnew.py.

◆ m_TrackMinWidth

pcbnew.BOARD_DESIGN_SETTINGS.m_TrackMinWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TrackMinWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TrackMinWidth_set, doc=)

static

Definition at line 12123 of file pcbnew.py.

◆ m_TrackWidthList

pcbnew.BOARD_DESIGN_SETTINGS.m_TrackWidthList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_TrackWidthList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_TrackWidthList_set, doc=)

static

Definition at line 12110 of file pcbnew.py.

◆ m_UseConnectedTrackWidth

pcbnew.BOARD_DESIGN_SETTINGS.m_UseConnectedTrackWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UseConnectedTrackWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UseConnectedTrackWidth_set, doc=)

static

Definition at line 12118 of file pcbnew.py.

◆ m_UseHeightForLengthCalcs

pcbnew.BOARD_DESIGN_SETTINGS.m_UseHeightForLengthCalcs = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UseHeightForLengthCalcs_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UseHeightForLengthCalcs_set, doc=)

static

Definition at line 12178 of file pcbnew.py.

◆ m_UserLayerNames

pcbnew.BOARD_DESIGN_SETTINGS.m_UserLayerNames = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_UserLayerNames_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_UserLayerNames_set, doc=)

static

Definition at line 12157 of file pcbnew.py.

◆ m_ViasDimensionsList

pcbnew.BOARD_DESIGN_SETTINGS.m_ViasDimensionsList = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasDimensionsList_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasDimensionsList_set, doc=)

static

Definition at line 12111 of file pcbnew.py.

◆ m_ViasMinAnnularWidth

pcbnew.BOARD_DESIGN_SETTINGS.m_ViasMinAnnularWidth = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinAnnularWidth_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinAnnularWidth_set, doc=)

static

Definition at line 12124 of file pcbnew.py.

◆ m_ViasMinSize

pcbnew.BOARD_DESIGN_SETTINGS.m_ViasMinSize = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinSize_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ViasMinSize_set, doc=)

static

Definition at line 12125 of file pcbnew.py.

◆ m_ZoneKeepExternalFillets

pcbnew.BOARD_DESIGN_SETTINGS.m_ZoneKeepExternalFillets = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneKeepExternalFillets_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneKeepExternalFillets_set, doc=)

static

Definition at line 12139 of file pcbnew.py.

◆ m_ZoneLayerProperties

pcbnew.BOARD_DESIGN_SETTINGS.m_ZoneLayerProperties = property(_pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneLayerProperties_get, _pcbnew.BOARD_DESIGN_SETTINGS_m_ZoneLayerProperties_set, doc=)

static

Definition at line 12158 of file pcbnew.py.

◆ thisown

pcbnew.BOARD_DESIGN_SETTINGS.thisown = property(lambda x: x.this.own(), lambda x, v: x.this.own(v), doc="The membership flag")

static

Definition at line 11839 of file pcbnew.py.

The documentation for this class was generated from the following file:

pcbnew.py

Public Member Functions

Properties

Detailed Description

Constructor & Destructor Documentation

◆ __init__()

Member Function Documentation

◆ __eq__()

◆ __ne__()

◆ CloneFrom()

◆ GetAuxOrigin()

◆ GetBiggestClearanceValue()

◆ GetBoardThickness()

◆ GetCopperLayerCount()

◆ GetCurrentDiffPairGap()

◆ GetCurrentDiffPairViaGap()

◆ GetCurrentDiffPairWidth()

◆ GetCurrentNetClassName()

◆ GetCurrentTrackWidth()

◆ GetCurrentViaDrill()

◆ GetCurrentViaSize()

◆ GetCustomDiffPairGap()

◆ GetCustomDiffPairViaGap()

◆ GetCustomDiffPairWidth()

◆ GetCustomTrackWidth()

◆ GetCustomViaDrill()

◆ GetCustomViaSize()

◆ GetDefaultZoneSettings()

◆ GetDiffPairIndex()

◆ GetDRCEpsilon()

◆ GetEnabledLayers()

◆ GetGridOrigin()

◆ GetHolePlatingThickness()

◆ GetLayerClass()

◆ GetLineThickness()

◆ GetSeverity()

◆ GetSmallestClearanceValue()

◆ GetStackupDescriptor()

◆ GetTeadropParamsList()

◆ GetTextItalic()

◆ GetTextSize()

◆ GetTextThickness()

◆ GetTextUpright()

◆ GetTrackWidthIndex()

◆ GetUserDefinedLayerCount()

◆ GetViaSizeIndex()

◆ Ignore()

◆ IsLayerEnabled()

◆ LoadFromFile()

◆ SetAuxOrigin()

◆ SetBoardThickness()

◆ SetCopperLayerCount()

◆ SetCustomDiffPairGap()

◆ SetCustomDiffPairViaGap()

◆ SetCustomDiffPairWidth()

◆ SetCustomTrackWidth()

◆ SetCustomViaDrill()

◆ SetCustomViaSize()

◆ SetDefaultMasterPad()

◆ SetDefaultZoneSettings()

◆ SetDiffPairIndex()

◆ SetEnabledLayers()

◆ SetGridOrigin()

◆ SetTrackWidthIndex()

◆ SetUserDefinedLayerCount()

◆ SetViaSizeIndex()

◆ UseCustomDiffPairDimensions()

◆ UseCustomTrackViaSize()

◆ UseNetClassDiffPair()

◆ UseNetClassTrack()

◆ UseNetClassVia()

Property Documentation

◆ m_AllowSoldermaskBridgesInFPs

◆ m_CapVias

◆ m_CopperEdgeClearance

◆ m_CoverViasBack

◆ m_CoverViasFront

◆ m_CurrentViaType

◆ m_DefaultFPTextItems

◆ m_DiffPairDimensionsList

◆ m_DiffPairMeanderSettings

◆ init()

◆ eq()

◆ ne()
